DIN 1691 Grade GG10 Gray Cast Iron

Commonly, grade GG10 cast iron is the lowest grade in standard DIN 1691.

Today, YIDE Casting gives you some examples of DIN 1691 GG10 gray cast iron applications for your reference.

For small loads, the friction and wear no special requirements for important casting, such as protective cover, cover, oil pan, hand wheels, frame, floor, hammer, small handle, counter weights etc.

Physical Properties of DIN 1691 GG10 Gray Cast Iron

Density ρ 6.8 – 7.8 g/cm³ at 20 °C Typical for Cast Iron

Mechanical Properties of DIN 1691 GG10 Gray Cast Iron

Shear modulus G 41 GPa at 20 °C Typical for Cast Iron
Tensile strength Rm 100 MPa at 20 °C

Equivalent Material Grades

Material Grade

Standard

Country Code

Tensile stress (Mpa)

Thick (mm)

GG-10

1691

DIN

≧100

≧30

HT-100

9439

GB

≧100

FC100

G5501

JIS

≧100

≧30

No. 20

A48

ASTM

≧138

≧30.5

FC100

2472

CNS

≧100

≧30
